Spillceptor®
FULL RETENTION OIL & WATER SEPARATOR
Spillceptor® is a full retention separator that treats all flows. It is to be sized to contain more than the anticipated maximum oil spillage — enabling it to be fully operational in treating stormwater runoff at all times.
It has two chambers, a coalescer and is fitted with an automatic closure device specifically designed to contain major oil spills, thereby making it suitable for high-risk applications. It achieves a water discharge quality of less than 5mg light liquids per litre, complying with European Standard BS EN 858.1. 2006. Treatable flow rates range from 2LPS to 200LPS. Pipe sizes range from 100mm to 450mm (larger sizes on request).
Features & Benefits
Efficient Spill Management
Designed to capture and contain hydrocarbons, oil, and grease during spill events, preventing environmental contamination.
Dual-Functionality
Operates as both a treatment device for everyday runoff and a containment system for emergency spill events.
Automated Closure System
Features an automatic shutoff valve to isolate and contain spills, ensuring maximum safety.
High Contaminant Retention
Effectively traps sediments, oil, and hydrocarbons within the treatment chamber.
Treatable Flow Rates
Treatment rates range from 2LPS to 200LPS. Pipe sizes range from 100mm to 450mm (larger sizes on request).
Robust Construction
Durable materials ensure long-term performance and resistance to harsh environmental conditions.
Easy Maintenance
Accessible design facilitates quick and straightforward cleaning and inspections.
| POLLUTANT | EFFICIENCY |
|---|---|
| Gross Pollutants (GP) | 100% |
| Total Suspended Solids (TSS) | 87% |
| Total Phosphorus (TP) | 11% |
| Total Nitrogen (TN) | 23% |
*Contact us to confirm approval performance for the project LGA.
Adaptable Configurations
Suitable for a range of installations, including industrial, commercial, and transportation hubs.
Compliance Assurance
Meets or exceeds statutory guidelines for spill management and stormwater treatment in Australia.
Manufactured in New Zealand
Locally fabricated in our National FRP production facilities to meet ISO9001 Quality Standards.
Applications
- Power Stations
- Substations & Switchyards
- Mining and Heavy Vehicles
- Windfarms
- Renewable Energy
- Waste Transfer Depots
- Re-Fuelling Areas
- Service Stations
- Asphalt Plants
